Technical Specifications

General

• Dimensions: Ø 65 x 40 mm
• Weight: 58.3 g (with packaging: 108 g)
• Color: White

Power supply

• Battery: 1 x CR123A, exchangeable
• Battery life: 5 years, reporting every 5 minutes
• Battery level and low battery warning are reported

Radio

• Sensitivity: -92 dBm
• Output power: Typ. +4 dBm

Environment

• IP class: IP20
• Operation temperature 0 to +50°C
• Relative humidity up to 95% non-condensing

Fire sensor

• Heat based fire sensing
• Siren output 85 dB/3m

Temperature sensor

• Range: 0 to +50°C
• Resolution: 0.1°C (accuracy Typ ±0.5°C and Max ±2°C)
• Reporting: configurable

Certifications

• Conforming to CE, RED and RoHS directives
• EN 54 and DIN 14676 certified
• Zigbee 3.0 certified
